Sawafi Motor

Sawafi 9 5/8" 7/8 Lobes 5.7 Stage Motor

Torque Slope

19.34 ft-lb/psi

REV / Gal

0.126 rev/gal

RPM

80 - 150 rpm

Flow range

600 - 1200 gpm

Max Differential

1340 psi

Max Power

651 hp

Bit Size Range

12-1/4 - 17-1/2 in in

Absolute Overpull

1235100 lbs

Max. Overpull

741100 lbs

Thread Protector

38000 ft-lbs

Adjustable Makeup Torque

60000 ft-lbs

Max Torque

25920 lb-ft

Stall Differential

2110 psi

Stall Torque

40830 lb-ft

Dynamic BL

240975 lbs

Static BL

852600 lbs

Weight

6178 pounds

Torque Slope

19.34 ft-lb/psi

REV / Gal

0.126 rev/gal

0.033 rev/lpm

RPM

80 - 150 rpm

Flow range

600 - 1200 gpm

2271 - 4542 lpm

Max Differential

1340 psi

9239 kPa

Max Torque

25920 ft. lbs

35143 N-m

Stall Differential

2110 psi

14548 kPa

Stall Torque

40830 lb-ft

55358 N-m

Dynamic BL

240975 lbs

1071 kN

Static BL

852600 lbs

3792 kN

Weight

6178 pounds

2802 kilos

Bit to Stab

18.50 in

Bit to Bend

87.00 in

Slick OD

9.62 in

Wear Pad OD

10.25 in

Overall Length

393.50 in

Top Connection

6-5/8 or 7-5/8

Bottom Connection

6-5/8 or 7-5/8" Reg

Adjustable Bend Motor Lengths

Bit to Stab

18.50 in

Bit to Bend

87.00 in

Overall Length

393.50 in

Slick OD

9.62 in

Wear Pad OD

10.25

Top Connection

6-5/8 or 7-5/8

Bottom Connection

6-5/8 or 7-5/8

Top Connection

6-5/8 or 7-5/8

Bottom Connection

6-5/8 or 7-5/8

Predicted Build Rates (Degrees per 100 ft/30 m)
Bend Slick Single Stabilizer
12 ¼ 14 16 17 ½ 12 ¼ 14 16 17 ½
0.39 - - - - 2.50 - - -
0.78 1.40 - - - 4.50 5.40 6.50 -
1.15 3.70 0.60 - - 6.60 7.30 8.40 9.20
1.50 5.90 2.80 - - 8.20 9.10 10.20 11.00
1.83 8.00 4.90 1.40 - 9.90 10.80 11.90 12.60
2.12 9.90 6.80 3.20 0.50 11.40 12.30 13.30 14.10
2.38 11.50 4.90 4.90 2.20 12.70 13.60 14.70 15.50
2.60 12.90 6.30 6.30 3.60 13.80 14.70 15.80 16.60
2.77 14.00 7.30 7.30 4.70 14.70 15.60 16.60 17.40
2.90 14.80 8.20 8.20 5.50 15.30 16.30 17.30 18.10
2.97 15.20 8.60 8.60 5.90 15.70 16.60 17.70 18.50
3.00 15.40 8.80 8.80 6.10 15.80 16.80 17.80 18.60
FBH Build Rates (Degrees per 100 ft/30 m)
Bend Slick Single Stabilizer
12 ¼ 14 16 17 ½ 12 ¼ 14 16 17 ½
1.25 4.80 1.70 - - 6.90 7.80 8.90 9.70
1.50 6.40 3.20 - - 8.20 9.10 10.20 11.00
1.75 7.90 4.80 1.30 - 9.50 10.40 11.50 12.20
2.00 9.50 6.40 2.90 0.20 10.70 11.70 12.70 13.50
2.25 11.10 8.00 4.50 1.80 12.00 12.90 14.00 14.80
2.50 12.70 9.60 6.00 3.40 13.30 14.20 15.30 16.10
